Penn Squall II 40 9kg 563g 5.3:1

Penn Squall II 40 — lightweight power for nearshore trolling

The Penn Squall II Lever Drag 40 combines a lightweight graphite frame with stainless steel gears and the proven Dura-Drag™ system, delivering serious stopping power for dolphin, kingfish, and other nearshore predators.

Graphite construction for all-day comfort

The one-piece graphite frame and palm sideplate keep the weight down to 563 g without sacrificing strength. The forged and machined aluminum spool is built to handle hard runs, while the corrosion-resistant design stands up to saltwater use. Line capacity rings help you monitor how much line is out during the fight.

Reliable drag control and smooth retrieval

Stainless steel main and pinion gears paired with the Dura-Drag™ system provide consistent stopping power up to 9 kg. The Pull-to-Turn preset knob prevents accidental drag adjustments when you're focused on the fish. Five bearings (4 stainless steel ball bearings plus a double dog ratchet anti-reverse) ensure smooth operation, and the 5.3:1 gear ratio recovers 91 cm of line per turn.

Choose the right variant

The Squall II Lever Drag family offers six models for different fishing situations:

• 25N (Size 25) — 535 g, 5.3:1 ratio, 13.6 kg max drag, 330/20 m/lb capacity — lighter lines for wreck fishing and conger

• 30 (Size 30) — 553 g, 5.3:1 ratio, 5.8 kg max drag, 405/25 m/lb capacity — mid-range option for cod and ling

• 40 (Size 40) — 563 g, 5.3:1 ratio, 9 kg max drag, 400/30 m/lb capacity — nearshore trolling for dolphin and kingfish

• 40N High Speed (Size 40) — 563 g, 7.1:1 ratio, 9 kg max drag, 715/16 m/lb capacity — faster retrieve for vertical jigging and live-bait fishing

• 50 (Size 50) — 683 g, 4.8:1 ratio, 12.2 kg max drag, 410/40 m/lb capacity — heavier lines for larger predators

• 60 (Size 60) — 692 g, 4.8:1 ratio, 14.9 kg max drag, 355/50 m/lb capacity — maximum drag for halibut, big sharks, and tough bottom fish

Facts

• Reel size: 40

• Weight: 563 g

• Gear ratio: 5.3:1

• Line retrieve per turn: 91 cm

• Max drag: 9 kg

• Bearings: 5 (4 stainless steel ball bearings + double dog ratchet)

• Mono capacity: 365 m / 0.54 mm, 285 m / 0.61 mm, 210 m / 0.71 mm (400 yd / 30 lb, 310 yd / 40 lb, 230 yd / 50 lb)

• Braid capacity: 705 m / 0.41 mm, 585 m / 0.39 mm, 505 m / 0.49 mm (770 yd / 50 lb, 640 yd / 65 lb, 555 yd / 80 lb)

• Drag system: Dura-Drag™, lever drag

• Spool material: forged and machined aluminum

• Frame: one-piece graphite

• Anti-reverse: double dog ratchet

• Hand retrieve: right
